PC-4GF

Integrated Photovoltaic Environmental Monitoring   Instruments

Measurement of 5 elements: ambient   temperature, ambient humidity, wind speed, wind direction, total solar   radiation

2

PC-5GF

Photovoltaic environmental   monitoring instruments

Measurement of 7 elements: ambient   temperature, ambient humidity, wind speed, wind direction, rainfall, total   solar radiation (horizontal tilt angle adjustable)

3

PC-2-T2

Photovoltaic Environmental   Monitoring System

3.1

PTS-3

Ambient temperature and humidity   sensors

Measurement of ambient temperature,   ambient humidity

3.2

QA-1

Air Pressure Sensor

Measurement of atmospheric pressure

3.3

EC-8SX

Integrated Digital Wind Speed and   Direction Sensor

Measurement of wind direction and speed

3.4

TBS-YG1

Fully automated solar radiation   sensors

Measurement of total radiation,   scattered radiation, direct radiation, sunshine reality

3.5

PTWD-2A

Backplane Temperature Sensor

Measurement of solar panel backplane   temperature

3.6

TBQ-2

Total radiation meter

Total radiation meter (angle   adjustable)

3.7

TRM-ZS1

data collector

Acquisition and analysis of recorded   real-time data

3.8

TRM-ZJ

Bracket

4

YGF-2

Dust Monitoring System for Solar Panel

Measurement and calculation of the   contaminant index of the battery panels, the index of power loss due to dust

5

TBS-4

Fully Automatic Solar Photometer

Measures ten bands of direct solar   radiation, as well as total solar radiation, scattered radiation, hours of   sunshine, solar altitude angle, atmospheric aerosol thickness, and many other   elements.

6

YG-JG

Silicon based irradiance sensors

Solar irradiance measurement sensors

7

TBQ-2WX

Solar Radiation Calibrator

Calibration of field-installed solar   radiation sensors

8

TBK11

All-sky imager

An all-sky cloud analysis system that   records all-sky cloud distribution data for monitoring weather and cloud   changes, solar energy capacity forecasting, and PV power generation   performance evaluation, etc.

9

JGXS-GF

Scanning Snow Thickness Gauge for Photovoltaic   Power Plants

Monitoring of snow on photovoltaic panels   with programmable scanning of multiple points

10

YG-WSD

Energy Storage Silo Temperature and Humidity   Recorder

Mainly in storage boxes or prefabricated   chambers to monitor ambient temperature

11

EC-A6

Three-dimensional ultrasonic wind direction and   speed sensor

Measurement of X, Y, Z axis wind speed,   horizontal and vertical wind direction
